TV ve uydu kabloları
75 Ohm Koaksiyel, TV ve UYDU
Kablo TV, uydu anten ve genişbant dağıtım sistemleri için 75 ohm koaksiyel kablolar: RG-6, RG-11, RG-59, H125 ve ana arter kabloları; ayrıca SDI video, CCTV ve triax. Belden ve Telegärtner ürünlerini kodu ve metrajıyla isteyin.
- RG-6 · RG-11 · RG-59
- CATV 0,1–862 MHz
- Uydu 950–2400 MHz
- Tri-Shield · Quad Shield
- Yaygın modeller stokta
- Kesilmiş metraj
Belden ve Telegärtner tek tedarikçiden
Yaygın kullanılan modelleri stokta bulunduruyoruz. Makara yerine ihtiyacınız kadar kesilmiş metraj alabilirsiniz. Türkiye’ye ve tüm dünyaya satış yapıyoruz.
Ürün koduyla teklif isteyin Uygun kabloyu seçmeme yardımcı olun
TV, uydu ve video için 75 ohm kablo seçimi
Kablo şu sırayla belirlenir: 1. uygulama ve frekans bandı, 2. mesafeye göre kablo sınıfı (RG-59, RG-6, RG-7, RG-11 ya da ana arter kablosu), 3. ekran yapısı (folyo ve örgü, üç katlı, dört katlı), 4. kullanım yerine göre kılıf (bina içi PVC ya da halojensiz, dış ortam ve yeraltı için PE, askı telli).
| Uygulama | Frekans bandı | Seçimde öne çıkan ölçütler |
|---|---|---|
| Kablo TV (CATV) | 0,1–862 MHz | Ekranlama etkinliği ve geri dönüş kanalı, yansıma kaybı, çekme dayanımı, neme ve korozyona dayanıklılık |
| Uydu TV (DTH, SMATV) | 950–2400 MHz | Bandın tamamında zayıflama, dış ortamda UV dayanımı, IF dağıtımı için ince ve esnek yapı |
| Ana arter ve bina dağıtımı | her iki bant | RG-11 ya da ana arter kablosu; yeraltında PE kılıf, havai hatta askı telli tip |
| Marka | Ürün yelpazesi |
|---|---|
| Belden | Genişbant, CATV ve uydu kabloları, Avrupa tipi H121–H126 ve ana arter kabloları, SDI ve analog video, CCTV, triax, Mil-Spec. 331 kod. |
| Telegärtner | Low Loss HD FRNC (0.6/2.8, 0.8/3.7, 1.0/4.8, 1.6/7.3), RG-59 ve RG-179. 11 sipariş numarası. |
TV ve uydu şebekelerinin ana arterinde fiber kullanılıyorsa fiber optik kablo sayfasına bakın.
TV, uydu ve genişbant kabloları: RG-6, RG-11, RG-59, H125 ve ana arter
100 Belden kodu. Kablo TV, uydu (DBS) ve genişbant dağıtım kabloları; folyo ve örgü, Tri-Shield ve Quad Shield ekranlı tipler.
| Marka | Ürün veya kod | Ayrıntı |
|---|---|---|
| RG-11 ve Series 11 (20) | ||
| Belden | 1153A | CATV Video, RG11 Type, 14 AWG BCCS, Quad Shield (Foil + 60% Braid + Foil + 40% Braid), CMP |
| Belden | 1523A | Broadband Coax, Series 11, 14 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt, CM |
| Belden | 1523AP | Broadband Coax, Series 11, 14 AWG Solid BCCS, Foil + 60% AL Braid, PVDF Jkt, CMP |
| Belden | 1523R | Broadband Coax, Series 11, 14 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt, CMR |
| Belden | 1524AM | CATV Video, RG11, 14 AWG BCCS, Foil + Braid, Messenger, PVC Jacket |
| Belden | 1525A | Broadband Coax, Series 11, 14 AWG Solid BCCS, Foil + 60% AL Braid, PE Jkt, Waterblocked |
| Belden | 1617A | Broadband Coax, Series 11, 14 AWG Solid BCCS, Quad Shield, PVC Jkt, CM |
| Belden | 1617AP | Broadband Coax, Series 11, 14 AWG Solid BCCS, Quad Shield, PVDF Jkt, CMP |
| Belden | 1617R | CATV Video, RG11, 14 AWG BCCS, Quad Shield, CMR |
| Belden | 1618A | CATV Video, RG11, 14 AWG BCCS, Quad Shield , Waterblocked |
| Belden | 1619AM | CATV Video, RG11, 14 AWG BCCS, Quad Shield, Messenger |
| Belden | 7999AP | Broadband Coax, Series 11, 14 AWG Solid BCCS, Quad Shield, PVDF Jkt, CMP |
| Belden | 9764 | CATV Video, RG11, 14 AWG BCCS, Tri Shield, Polyethylene Jacket |
| Belden | PRG11A2 | Broadband Coax, RG11 Type, 15 AWG Solid BC, Foil + 45% TC Braid, PVC Jkt |
| Belden | PRG11C0 | Broadband Coax, RG11 Type, 15 AWG Solid BC, CU-Foil + 45% BC Braid, PE Jkt |
| Belden | PRG11C2 | Broadband Coax, RG11 Type, 15 AWG Solid BC, CU-Foil + 45% BC Braid, LSZH Jkt |
| Belden | PRG11C4 | Broadband Coax, RG11 Type, 15 AWG Solid BC, CU-Foil + 45% BC Braid, PVC Jkt |
| Belden | PRG11D0 | Broadband Coax, RG11 Type, 15 AWG Solid BC, Tri Shield, 70% TC Braid, PVC Jkt |
| Belden | PRG11D1 | Broadband Coax, RG11 Type, 15 AWG Solid BC, Tri Shield, 70% TC Braid, LSZH Jkt |
| Belden | PRG11D3 | Broadband Coax, RG11 Type, 15 AWG Solid BC, Tri Shield, 70% TC Braid, PE Jkt |
| RG-7 ve Series 7 (2) | ||
| Belden | PRG7C00 | Broadband Coax, RG7 Type, 17 AWG Solid BC, CU-Foil + 30% BC Braid, PVC Jkt |
| Belden | PRG7C01 | Broadband Coax, RG7 Type, 17 AWG Solid BC, CU-Foil + 30% BC Braid, PE Jkt |
| RG-6 ve Series 6 (30) | ||
| Belden | 1152A | Broadband Coax, Series 6, 18 AWG Solid BCCS, Quad Shield, FEP Jkt, CMP |
| Belden | 1189A | Broadband Coax, Series 6, 18 AWG Solid BCCS, Quad Shield, PVC Jkt, CM |
| Belden | 1189AP | Broadband Coax, Series 6, 18 AWG Solid BCCS, Quad Shield, Flamarrest® Jkt, CMP |
| Belden | 1190A | CATV Video, RG6, 18 AWG BCCS, Quad Shield (Foil + 60% Braid + Foil + 40% Braid), Waterblocked |
| Belden | 1191AM | CATV Video, RG6, 18 AWG BCCS, Quad Shield, Messenger |
| Belden | 1322R | CATV Video, RG6, 18 AWG BCCS, Quad Shield, CMR |
| Belden | 1530A | CATV Video, RG6, 18 AWG BCCS, Foil + Braid, CM PVC Jacket |
| Belden | 1530AP | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 90% AL Braid, Flamarrest® Jkt, CMP |
| Belden | 1532A | CATV Video, RG6, 18 AWG BCCS, Foil + Braid, Waterblocked, PVC Jacket |
| Belden | 1545A | CATV Video, RG6, 18 AWG BCCS, Foil + Braid, Waterblocked, CM PVC Jacket |
| Belden | 1613A | CATV Video, RG6, 18 AWG BCCS, Tri Shield, CM PVC Jacket |
| Belden | 1613AP | Broadband Coax, Series 6, 18 AWG Solid BCCS, Tri-Shield, Flamarrest® Jkt, CMP |
| Belden | 1829A | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt, CM |
| Belden | 1829AC | Broadband Coax, Series 6, 18 AWG Solid BC, Foil + 60% AL Braid, PVC Jkt, CM |
| Belden | 1829P | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, Flamarrest® Jkt, CMP |
| Belden | 1829R | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt, CMP |
| Belden | 1839A | DBS Cable, RG6, 18 AWG BCCS, Foil + Braid, Messenger |
| Belden | 1841A | DBS Cable, Dual RG6, 18 AWG BCCS, Foil + Braid, CM |
| Belden | 7915A | Broadband Coax, Series 6, 18 AWG Solid BC, Tri-Shield, PVC Jkt, CM |
| Belden | 7916A | DBS Cable, RG6, 18 AWG BC, Quad Shield, CM |
| Belden | 7916AP | Broadband Coax, Series 6, 18 AWG Solid BC, Quad Shield, Flamarrest® Jkt, CMP |
| Belden | 9058 | CATV Video, RG6, 18 AWG BCCS, Tri Shield, CM PVC Jacket |
| Belden | 9066 | CATV Video, RG6, 18 AWG BCCS, Foil + Braid |
| Belden | 9077 | CATV Video, Dual RG6, 18 AWG BCCS, Foil + Braid, CM PVC Jacket |
| Belden | 9116 | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt, CM |
| Belden | 9116E | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt |
| Belden | 9116P | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, Flamarrest® Jkt, CMP |
| Belden | 9116R | Broadband Coax, Series 6, 18 AWG Solid BCCS, Foil + 60% AL Braid, PVC Jkt, CMR |
| Belden | 9117M | CATV Video, RG6, 18 AWG BCCS, Messenger |
| Belden | 9118 | CATV Video, RG6, 18 AWG BCCS, Tri Shield, CM PVC Jacket |
| RG-59 ve Series 59 (2) | ||
| Belden | 9104 | Broadband Coax, Series 59, 20 AWG Solid BCCS, Foil + 65% AL Braid, PVC Jkt, CM |
| Belden | 82108 | CATV Video, RG59, #20 BCCS, Foil + 95% Braid, CMP |
| Avrupa tipi: H121, H123, H124, H125, H126 (30) | ||
| Belden | H121A00 | Broadband Coax, H121, 20 AWG Solid BC, Foil + 45% TC Braid, PVC Jkt |
| Belden | H121A01 | Broadband Coax, H121, 20 AWG Solid BC, Foil + 45% TC Braid, PE Jkt |
| Belden | H121A02 | Broadband Coax, H121, 20 AWG Solid BC, Foil + 45% TC Braid, PVC Jkt, Twin-coax |
| Belden | H121A03 | Broadband Coax, H121B, 20 AWG Solid BC, Foil + 75% TC Braid, PVC Jkt |
| Belden | H121A04 | Broadband Coax, H121B, 20 AWG Solid BC, Foil + 75% TC Braid, LSZH Jkt |
| Belden | H121C00 | Broadband Coax, H121, 20 AWG Solid BC, CU-Foil + 45% BC Braid, PVC Jkt |
| Belden | H121T00 | Broadband Coax, H121T, 20 AWG Solid BC, Tri-Shield, PVC Jkt |
| Belden | H121T01 | Broadband Coax, H121T, 20 AWG Solid BC, Tri-Shield, LSZH Jkt |
| Belden | H123A00 | Broadband Coax, H123, 22 AWG Solid BC, Foil + 45% TC Braid, PVC Jkt |
| Belden | H123A01 | Broadband Coax, H123B, 22 AWG Solid BC, Foil + 90% TC Braid, PVC Jkt |
| Belden | H123A02 | Broadband Coax, H123B, 22 AWG Solid BC, Foil + 90% TC Braid, LSZH Jkt |
| Belden | H124A00 | Broadband Coax, H124, 18 AWG Solid BC, Foil + 30% TC Braid, PVC Jkt |
| Belden | H124C01 | Broadband Triax, H124, 18 AWG Solid BC, CU-Foil + 40% BC Braid, LSZH Jkt, 60% BC Braid, LSZH Jkt |
| Belden | H124C02 | Broadband Coax, H124, 18 AWG Solid BC, CU-Foil + 40% BC Braid, LSZH Jkt |
| Belden | H125A00 | Broadband Coax, H125, 18 AWG Solid BC, Foil + 35% TC Braid, PVC Jkt |
| Belden | H125A01 | Broadband Coax, H125, 18 AWG Solid BC, Foil + 35% TC Braid, PE Jkt |
| Belden | H125A03 | Broadband Coax, H125, 18 AWG Solid BC, Foil + 35% TC Braid, LSZH Jkt |
| Belden | H125A06 | Broadband Coax, H125CH, 18 AWG Solid BC, Foil + 65% TC Braid, PVC Jkt |
| Belden | H125A07 | Broadband Coax, H125CH, 18 AWG Solid BC, Foil + 65% TC Braid, LSZH Jkt |
| Belden | H125C00 | Broadband Coax, H125, 18 AWG Solid BC, CU-Foil + 35% BC Braid, PVC Jkt |
| Belden | H125C01 | Broadband Coax, H125, 18 AWG Solid BC, CU-Foil + 35% BC Braid, PE Jkt |
| Belden | H125C03 | Broadband Coax, H125, 18 AWG Solid BC, CU-Foil + 35% BC Braid, PVC Jkt, Twin-coax |
| Belden | H125C04 | Broadband Coax, H125, 18 AWG Solid BC, CU-Foil + 35% BC Braid, LSZH Jkt |
| Belden | H125D00 | Broadband Coax, H125D, 18 AWG Solid BC, Tri-shield, PVC Jkt |
| Belden | H126D00 | Broadband Coax, H126D, 18 AWG Solid BC, Tri-shield, PVC Jkt |
| Belden | H126D02 | Broadband Coax, H126D, 18 AWG Solid BC, Tri-shield, PVC Jkt |
| Belden | H126D03 | Broadband Coax, H126D, 18 AWG Solid BC, Tri-shield, LSZH Jkt |
| Belden | H126D04 | Broadband Coax, H126D, 18 AWG Solid BC, Tri-shield, PE Jkt |
| Belden | H126T00 | Broadband Coax, H126T, 18 AWG Solid BC, Tri-shield, PVC Jkt |
| Belden | H126T01 | Broadband Coax, H126T, 18 AWG Solid BC, Tri-shield, LSZH Jkt |
| Ana arter (trunk): Broadband Coax 3, 4, 6, 9 ve CTF (16) | ||
| Belden | CTF100 | Broadband Coax, 18 AWG Solid BC, Foil + 50% BC Braid, PVC Jkt |
| Belden | CTF125 | Broadband Coax, 16 AWG Solid BC, Foil + 50% BC Braid, PVC Jkt |
| Belden | CTF167P | Broadband Coax, 14 AWG Solid BC, Foil + 50% BC Braid, PE Jkt |
| Belden | CX3C0 | Broadband Coax 3, 8 AWG Solid BC, Foil + 60% BC Braid, PE Jkt |
| Belden | CX3C1 | Broadband Coax 3, 8 AWG Solid BC, BC Foil, PE Jkt |
| Belden | CX3C2 | Broadband Coax 3, 8 AWG Solid BC, Foil + 60% BC Braid, LSZH Jkt |
| Belden | CX3C5 | Broadband Coax 3, 8 AWG Solid BC, Foil + 60% BC Braid, HDPE Jkt |
| Belden | CX3C8 | Broadband Coax 3, 8 AWG Solid BC, Foil + 60% BC Braid, LSZH Jkt |
| Belden | CX4C0 | Broadband Coax 4, 11 AWG Solid BC, Foil + 60% BC Braid, PE Jkt |
| Belden | CX4C1 | Broadband Coax 4, 11 AWG Solid BC, BC Foil, PE Jkt |
| Belden | CX4C2 | Broadband Coax 4, 11 AWG Solid BC, Foil + 60% BC Braid, LSZH Jkt |
| Belden | CX6C0 | Broadband Coax 6, 14 AWG Solid BC, Foil + 60% BC Braid, PE Jkt |
| Belden | CX6C2 | Broadband Coax 6, 14 AWG Solid BC, Foil + 60% BC Braid, LSZH Jkt |
| Belden | CX9A2 | Broadband Coax 9, 17 AWG Solid BC, Foil + 70% BC Braid, PVC Jkt |
| Belden | CX9D0 | Broadband Coax 9, 17 AWG Solid BC, Trishield, PVC Jkt |
| Belden | CX9D1 | Broadband Coax 9, 17 AWG Solid BC, Trishield, LSZH Jkt |
