DVEO Ad Serter – IPTV Playout ve Ekrana Reklam Banner Ekleme Sunucusu
Canlı veya Kayıt Yayın için playout ve reklam sunucusu: DVEO Ad Serter
DVEO Ad Serter IP/IP ile 30 kanala kadar IPTV yayın ekranına reklam ekleyebilirsiniz.
- Yayın akışının üzerine banner, logo, kayan yazı, grafik, clip ekleyebilirsiniz
- Eşzamanlı olarak 30 SD yayın veya 8 720p yayın veya 8 1080p yayın destekler
- Türkçe desteği vardır
- Playout zamanlaması yapabilirsiniz
- IP giriş/çıkış dışında ASI giriş/çıkış ve SDI giriş/çıkışlı modelleri de mevcuttur
- Aurora 3D Maker for Windows yazılımı beraberinde verilmektedir
Live or Stored Content playout and AD server for 4 or 30 Live and Stored IP Feeds. Includes Traffic and Scheduling. Supports SCTE-035 and any others triggers.
Telco Quality, Real Time, High Density, 4 or 30 program, Web Manageable, H.264 or MPEG-2 Oriented, Automated Content and Ad Server with the Ability to Play Out Live and Stored Content on a Schedule with Flexible Standards Compliant Ad, Logo, or Clip Insertion or Splicing. Supports SCTE-35 and EAS Triggers and will Splice in Internal or External Live Clips as Needed.
Designed for Professionals Who are Ready to Move to Powerful Computer Platforms that can Give Them Everything Needed to Operate Channels in a Single Box.
Perfect for Insertion of Video or SuperPosition of Targeted Ads, News Tickers, EAS Messages, or Banner Ads on Mobile Services.
Ads can be Spliced into Live Stream or Overlaid Anywhere. Keeps Track of Ads Served.
Amazingly Flexible.
Deployed at Major Cable Company to Originate Important Messages to Entire Subscriber Base.
Ships with Graphics Creation Application but can use Most Graphics Formats.
Standard Features
- Complete scheduled playout system
- Inserts or overlays graphical ads, video clips, logos, graphics, CG, scrolling text, and emergency alerts into live and stored video feeds on a schedule or via signaling like SCTE-35
- 4 channel model: Simultaneously processes up to 4 SD streams, or 1 HD Stream
- 30 channel model: Simultaneously serves and supports up to 30 SD streams, or 8 720p streams, or 8 1080p streams
- Passes through Closed caption, AFD and other user data
- Secure Remote Scheduling from anywhere via Web Interface
- Generates playlists for time-shifted content that includes long form spots, all national ads, local ads and content.
- Built in intelligence makes scheduling easy
- IP input and output for multi screen implementations
- Supports 1080p, 1080i, 720p, and 480i, and all standard broadcast resolutions
- Selects transport streams by program numbers or PIDs
- Features daily, weekly, and monthly schedule-based logos, alerts, and text insertion
- Arbitrary location for graphics
- Choose from static, rotating, flipping, or blinking graphics, logos, and text
- Manages Ad inventories, logs Ad Plays, and generates Proof of Play list
- Creates crawling messages and emergency alerts with programmable fonts and background colors, in any language
- Creates Real Time Clock display in programmable fonts and colors anywhere on screen
- Displays remaining and next advertisement Time in output video
- Scales Input video from 10% to 100% and overlay on graphics – Ideal for EPG
- Overlays animating PNG files and scales Input Video from 10% to 100% – Ideal for L-Wrap, L-Squeeze and transparent overlays. Video squeezes.
- Select any degree of transparency
- Easy drag and drop placement to position logo, text, or graphics on screen
- News feeds from RSS in any language, with programmable fonts and background colors
- Able to mask entire screen with a static image in case of video input failure
- Auto Bypass in case of power failure of Ad Serter
- Sun Fade Detection to play prerecorded content on Solar Flare Days
- Optional Live Recorder function to record live content to play in the case of loss of input signal
- Service Schedule for maintenance of antenna or other infrastructure
- 1 RU or 3 RU rack mountable frame
- Web based GUI with multi-level access control and Drop Box Inputs for all content
- Template based character generator. Supports 3D fonts.
- Works as a playout server – with or without input signal EAS support is standard
- SLATE function puts up an Empty Background on which you can type messages
- Comprehensive Customization to your needs is possible
- ESAM support in development
- Stores and manages Content, Ads, Messages, and Graphics clips, on local RAID
- Optional analog Cue Tone Detection
- Supports many forms of GPI
- Ships with a copy of Aurora 3D Maker for Windows
- We are now working on Advertising Templates which will be adaptable by you for both for Product Advertising and Weather Type information channel
Applications
- Use existing content from: Graphics Libraries, RSS feeds*, web cams, video clips, flash streams, and animation files
- Ad overlays or Inserts for Web Streaming, OTT, IPTV, mobile video, cell, etc.
- Ideal POP UP ad creator
- Mobile Ad Delivery Platform
- Crawling text and graphics overlay for local advertising and announcements, station logo, KLV Metadata, etc.
- Add logos, graphics, and text to news broadcast segments – Weather, Sports, etc.
- Emergency alert system for Broadcast and Cable
- Video Messaging System
- Adding Instrumentation Data Video
- Targeted advertising
- Voting and TV Interaction systems
- Newstickers and PSA Crawls
- MOBILE EAS – Emergency Alert
