Fiber Optic Fusion Splicers, Termination

Fusion Splicers, Fiber Mounting Kit, Cover, Finishing, Installation Service

Fiber optic cable assembly, maintenance, measurement reporting procedures and equipment relating to the operation acceptance test, apparatus. Fiber optic training.

Fusion Splicer

PACIFIC PA 3000

Fully automatic operation
insertion loss estimate
tensile testing after adding Made
Built-in ovens
Easy to use, big screen
Intense suitable for
international 2 year warranty
Very durable construction
service in PROTEL site in Turkey
Free user training
inside the open-air or building, windy and suitable for use in dusty environments

Supplied with:

carrying bag,
fiber cutter,
fiber stripper,
250μm fiber holder
900μm fiber holder
One pair of auxiliary electrodes
charge adapter

PROTEL in-house technical service
free user training
2 year warranty

Technical specifications:

Description: three-axis fiber optic joint apparatus (Fusion Splicer)
Adding his fiber types: singlemode (ITU-TG.652) Multimode (ITU-TG.651), DS (ITU-TG.653) (ITU-TG.657) NZDS (ITU-TG.655)
Fiber diameter: Coating diameter: 100-1000μm, core diameter: 80-150μm
Stripping fiber length: 10-16mm (Coating diameter: 250μm)
The actual average insertion loss: 0.02db (SM), 0.01db (MCC), 0.04db (DS) 0.04db (NZDS)
Added time: Typically 10 seconds
The return loss:> 60 dB
Adding methods can be selected: Automatic, Semi-Automatic, Manual
Baking time: Typically 36 seconds
Sleeve length: 40mm or 60mm
Adding data memory: Internal memory can record 1000 results
Fiber image magnification: Vertical 155x, 310x horizontal
Battery capacity: 220 and shrink with the addition of one filling process
Display: 5.1-inch color LCD monitor, 640 x 480 resolution
Tensile test: 2 N (optional)
Electrode life: Typical insertion 5000
Interface: USB
Power supply: 11.8V lithium battery and AC adapter (input) AC100 ~ 240 DC12.6V, 5a (output)
Operating environment: 15m / s wind and dust protection cover
Dimensions: × W × H = 169 × 152 × 155 (mm)
Weight: 2.4kg (battery), 2.9kg (coil)
Other features include: advanced fiber profiles centering system
that does not require parameter setting, real-time calibration system
battery life precisely and displays in real-time
night work for high-brightness LED lighting
transmits the measurement results to a USB computer connection, the software update
when the insertion cap and the oven door closed process starts automatically

PROTEL, PACIFIC Fiber Optics is the only authorized distributor and service center in Turkey in general.

Brochure

User Manual (English)

Fusion Splicer

EASYSPLICER MK 2

New Easysplic MK 2 model
Fully automatic operation
insertion loss estimate
tensile test after adding Made
Built-in ovens
Easy to use, easy to transport (about POS machine sizes)
Turkish menu
2-year international warranty from
the sole splice device manufactured in Europe (Sweden goods)
in Turkey PROTEL on-site service
free user training
FTTH, CCTV installation, ideal for fiber optic technicians engaged in deployment inside buildings

V-slot single axis fiber optic splice device, the furnace, fully automatic.

very easy and very affordable to add the fiber is no longer with easysplic
Singlemode (SM) and multimode (MM) for the fiber (fiber lengths may G.657)
V-bulb (V-groove) type splice device
Low insertion loss. SM fiber <0.03 dB, MM fiber <0.01 dB typical loss value.
7 seconds to add processing time.
Single-axis fully automatic operation.
One battery filling by adding 60 + seat heating capacity.
Shrinking oven time 35 seconds
Very easy to use. Fully automatic operation.
1 MB internal memory; also an SD card slot
2.8-inch color display
Transferring SD memory card through the computer all the opportunity to add parameters and performance results
USB connection for installing the device firmware in the future will be free of charge through the interface opportunity
Very low operating costs.

Supplied with:

carrying bag,
fiber cutter,
fiber stripper,
250μm fiber holder
900μm fiber holder
Loose tube fiber holder
charge adapter

technical service within the PROTEL
Free user training
2 year warranty

Explanation:

easysplic the everyday suitable for use, new technology, is one of a type of a fiber optic splice device.

Known for its durable and high quality industrial products are manufactured in Sweden.

Small and handy. It has a very stable structure. It is designed for use in the field.

It is completely different from the mounted and designed with user-oriented design easysplicer other splice device. Additional learned in a much shorter time than other devices on the market, began to be used. Our typical training time is 1 hour. After 1 hour, add people who have not been before work can even begin.

easysplic will be just 3 buttons control. Despite this sensitivity it is very high. After insertion in insertion loss goals typical Single Mode fiber is about 0.03 dB. After addition makes the insertion point in stretching shear test determines the estimated value of the insertion loss, warns if there are any problems. Dirty fiber, also warns users before adding fiber in bad condition.

Li-Ion battery inside the device is quite small but powerful. The device can perform about 60 insertion and retraction oven battery with a single filling. The internal battery may be charged while the device is in use.

easysplic as it continuously, calibrates against changes in environmental conditions (changes in the rate of moisture for example). The calibration process can also be done manually (eg at study start). The calibration process takes place within a few seconds and easily add the results will contribute to be perfect.

V-chamber for adding easysplic (V-grove) building (method of use of ribbon fiber splicers). This way, the dimensions can be small.

Although most economical splice device of easysplic market, provides the performance of two to three times more expensive devices.

Technical specifications:

The method of adding V-slot (covering over fiber-alignment)
Fiber: SMF (9 / 125μm), MMF 50 / 125μm and 62.5 / 125μm fiber (G.651, G.652, G.653, G.657 can add fiber) primary and secondary coated fiber 900μm
Fiber holders are provided in three pairs with (250μm to 900μm and loose tube fiber)
Adding program: 3 pre-defined schedule. Singlemode, and multimode OM1
Typical losses value: 0.03db SMF, MMF 0.01db
Typical addition time: 7s + 35s (addition time + bake time)
Sleeve Size: 64mm length by the Bakery, so all sizes are supported 2-5mm diameter
Computer connection: USB, mini USB connection
Memory: 1 MB of internal, external SD-card
Monitor: Color LCD, 2.8-inch, 320 × 240 pixels
Magnifier: Camera 140x
Operating environment: 0 to 45 ° C, 95% humidity max
Dimensions: 230x98x53mm
Weight: 800g
Power supply: External power supply 6V, 1.25, or 100-240VAC 50-60Hz Built-in Li-Ion battery
Adding capacity: 60 by adding a battery filling in shrinkage oven +
Electrode life: adding about 5000
Other features include: After adding the insertion loss, fiber fault locator, tensile test, an SD card slot for adding value to record

PROTEL, easysplicer Turkey is the only authorized general distributor and service center.

Brochure

Easysplicer ictroduction

Fusion Splicer

EASYSPLICER

Fully automatic operation
insertion loss estimation
performed tensile test after adding
built-in oven
Easy to use, easy to transport (about POS machine sizes)
Turkish menu
2-year international warranty from
the sole splice device manufactured in Europe (Sweden Made)
served in PROTEL site in Turkey
Free users training
FTTH, CCTV installation, ideal for indoor distribution fiber optic technician who

V-slot single axis fiber optic splice device, the furnace, fully automatic.

very easy and very affordable to add the fiber is no longer with easysplic
Singlemode (SM) and multimode (MM) for the fiber (fiber lengths may G.657)
V-bulb (V-groove) type splice device
Low insertion loss. SM fiber <0.03 dB, MM fiber <0.01 dB typical loss value.
7 seconds to add processing time.
Single-axis fully automatic operation.
One battery filling by adding 60 + seat heating capacity.
Shrinking oven time 40 seconds
Very easy to use. Fully automatic operation.
1 MB internal memory; also an SD card slot
2.8-inch color display
Transferring SD memory card through the computer all the opportunity to add parameters and performance results
USB connection for installing the device firmware in the future will be free of charge through the interface opportunity
Very low operating costs.

Supplied with:

carrying bag,
fiber cutter,
fiber stripper,
250μm fiber holder
900μm fiber holder
charge adapter

technical service within the PROTEL
Free user training
2 year warranty

Explanation:

easysplic the everyday suitable for use, new technology, is one of a type of a fiber optic splice device.

Known for its durable and high quality industrial products are manufactured in Sweden.

Small and handy. It has a very stable structure. It is designed for use in the field.

V-chamber for adding easysplic (V-grove) building (method of use of ribbon fiber splicers). This way, the dimensions can be small.

Although most economical splice device of easysplic market, provides the performance of two to three times more expensive devices.

Technical specifications:

The method of adding V-slot (covering over fiber-alignment)
Fiber: SMF (9 / 125μm), MMF 50 / 125μm and 62.5 / 125μm fiber (G.651, G.652, G.653, G.657 can add fiber) primary and secondary coated fiber 900μm
Fiber holder 2 are provided in pairs with (250μm and 900μm)
Adding program: 2 fixed program. Singlemode and multimode
Typical losses value: 0.03db SMF, MMF 0.01db
Typical addition time: 7s + 40s (addition time + bake time)
Sleeve Size: 64mm length by the Bakery, so all sizes are supported 2-5mm diameter
Computer connection: USB, mini USB connection
Memory: 1 MB of internal, external SD-card
Monitor: Color LCD, 2.8-inch, 320 × 240 pixels
Magnifier: Camera 140x
Operating environment: 0 to 40 ° C, 95% humidity max
Dimensions: 230x98x53mm
Weight: 800g
Power supply: External power supply 6V, 1.25, or 100-240VAC 50-60Hz Built-in Li-Ion battery
Adding capacity: 60 by adding a battery filling in shrinkage oven +
Electrode life: adding about 2000
Other features include: After adding the insertion loss, fiber fault locator, tensile test, an SD card slot for adding value to record
